STINGER SUB 18 G3

18” Passive Bass Reflex PA Subwoofer

Specifications

Product type	PA subwoofer
Type	passive
Low/mid driver dimensions	18 "
Woofer size	457.2 mm
Woofer magnet	Ferrite
Woofer brand	Custom-made
Woofer voice coil	4 "
Woofer voice coil (mm)	101.6 mm
Load rating (RMS)	800 W
Peak power	1600 W
Frequency response	35 - Crossover Hz
SPL (1W/1m)	100 dB
Max. SPL	129 dB
Impedance	8 Ohm(s)
Loudspeaker inputs	1
Speaker input connections	Speakon compatible
Loudspeaker outputs	1
Speaker output connections	Speakon compatible
Speakers per amplifier channel (DSP44/45K)	2
Cabinet material	18 mm Plywood
Cabinet surface	Polyurea
Cabinet construction	Bass Reflex
Width	677 mm
Height	547 mm
Depth	740 mm
Weight	40,6 kg

Product Code	LD OOU0P13
Condition	New
