AVR-A110
110th Anniversary Edition AV Receiver
Multichannel Surround
| DTS HD Master / DTS:X | Yes / Yes |
| DTS:X Pro | Yes |
| DTS Neo:X / DTS Neural:X | No / Yes |
| DTS Virtual:X | Yes |
| Dolby TrueHD / Dolby Atmos | Yes / Yes |
| Dolby ProLogic II / Dolby Surround | No / Yes |
| Dolby Height Virtualization | Yes |
| Front Wide Speakers: Dolby / DTS | Yes / Yes |
| Auro 3D | 13ch |
| IMAX Enhanced | Yes |
| MPEG-H | Yes |
| Multichannel Stereo | Yes |
| Max Number of Processing (Preamp) Channels | 13.2 |
Sound Enhancements
| Mono Block Power Amp Construction | Yes (L/R separated) |
| Discrete Power Amplifier | 13 |
| 110th Anniversary Audio Tuning | Yes |
| Iron diecast feet | Yes |
| Copper plated transformer base | Yes |
| Premium speaker terminals | Yes |
| All black interior | Yes |
| D.D.S.C. HD Digital | Yes (32 bit) |
| Pure Direct | Yes |
| High Grade Audio Components | Yes |
| Gold Plated RCA Terminals | Yes |
| Clock Jitter Reducer | Yes |
| Alpha Processing | AL32 Processing Multichannel |
| Audyssey | MultEQ XT32 |
| Audyssey Dynamic EQ / Dynamic Volume | Yes / Yes |
| Audyssey LFC | Yes |
| Audyssey APP Support | Yes |
| Compressed Audio Restorer | Yes |
Network
| HEOS Multiroom and Streaming | Yes |
| Lossy Formats: MP3 / WMA / AAC | Yes / Yes / Yes |
| Lossless Formats: FLAC / ALAC / WAV | Yes / Yes / Yes |
| DSD Audio Streaming | up to DSD5.6 |
| FLAC HD 192/24 | Yes |
| WAV 192/24 | Yes |
| ALAC 192/24 | Yes |
| Gapless playback | Yes (FLAC, WAV, ALAC, DSD) |
| AirPlay 2 | Yes |
| Roon Tested | Yes |
| Internet Radio | TuneIn |
| Spotify Connect* / Tidal* / Deezer* / others * | Yes / Yes / Yes / Yes |
| Amazon Prime Music* / Pandora* | Yes / Yes |
| Compatible with Remote APP for Smart Phones | Android / iOS |
| Compatible with Remote APP for Tablets | Android / iOS/Amazon Kindle |
| Ethernet Ports | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
HDMI
| HDMI Inputs: Back / Front | 7 / 1 |
| HDCP2.3 support | Yes |
| HDMI Outputs: Main / Zone | 2 / 1 |
| HDMI max Resolution (8k / 4k) | 8k/60 - 4k/120 |
| Video Conversion Analog -> HDMI | Yes |
| HDMI to HDMI Scaling | up to 8K 60/50 |
| HDMI: 8K / 4K / CEC / eARC | Yes / Yes / Yes / Yes |
| HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG | Yes / Yes / Yes / Yes |
| HDMI: ALLM / QMS / QFT / VRR | Yes / Yes / Yes / Yes |
| HDMI pass-though in standby mode | Yes |
| DSD Audio Capability | Yes |
Multi-room CI
| HEOS Multiroom integrated | Yes |
| TV Sound grouping | Yes |
| Multiroom zones | 3 |
| Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog | Yes (2ch) / Yes (2ch) / Yes / Yes |
| Zone Audio Output: Speaker / Preout | Yes / Yes |
| Zone HDMI Output from HDMI Source | Yes |
| Webbrowser Setup | Yes |
| IP Control / RS232 Control / Web Control / App Control | Yes / Yes / Yes / Yes |
| Remote In / Out | Yes / Yes |
| DC Trigger Output | 2 |
Others
| Voice Control - Works with Amazon Alexa | Yes |
| Voice Control - Google Assist / Apple Siri | Yes / Yes |
| Auto Speaker Setup by Microphone | Audyssey MultEQ XT32 |
| FL Display | 2 lines |
| Graphic User Interface - GUI | Advanced |
| ISF Certification | Yes |
| GUI Languages | 9 |
| Setup Assistant | Yes |
| Quick Select Plus / Quick Select | Yes / No |
| Firmware Update by: Network / USB | Yes / Yes |
| Variable Cross Over | Yes |
| Optimized Bass Redirection | Yes |
| Bass Sync | Yes |
| ECO Mode | Yes |
| Auto Power Off | Yes |
| Sleep Timer | Yes |
Inputs Outputs
| Composite In / Out | 4 / 2 |
| Component In / Out | 3 / 1 |
| HDMI In / Out | 7+1 / 3 |
| Multi-room Video Out: Video / HDMI | Yes / Yes |
| Analogue In/out | 6+1 / No |
| Phono (MM) In | Yes |
| Digital In: Optical / Coaxial | 2 / 2 |
| Multi-room Out: Analog / Digital | 2 / No |
| Multichannel Preout | Yes (15.2) |
| Subwoofer Out | 2 (independent) |
| 7.1 Multichannel Input | Yes |
| Speaker Terminal: Gold Plated Screw / Regular Screw | Yes / No |
| Number of Speaker Terminals | 15 |
| Speaker A / B | assignable |
| Bi-amp Drive | assignable |
| Multi-Room Speaker Terminal | assignable |
| Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB | No / No / No / Yes / Yes |
| USB Audio / Made for iPod / Made for iPhone | Yes / AirPlay / AirPlay |
Specifications
| Number of Power Amps | 13 |
| Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) | 150 W |
| Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) | 190 W |
| Power Output (6 ohm, 1 kHz, 1% 1ch Drive) | 210 W |
General
| vailable colors: Black / Premium Silver | Silver Graphite |
| Metal Front Panel | Yes |
| System Remote Control | RC-1221 |
| Pre-programmed / Learnable / LCD Display | Yes / Yes / Yes |
| Power Consumption in W | 900 |
| Power Consumption No-Sound (ECO On / Off) in W | 70 W / 125 W |
| Standby Consumption in W | 0.1 |
| CEC Standby Consumption in W | 0.5 |
| Network Control On Consumption in W | 3.7 |
Maximum Dimensions
Antenna: Horizontal: (W x D x H) in Inches
Antenna: Vertical: (W x D x H) in Inches
W/O Antenna: (W x D x H) in Inches | 17.1 x 19.0 x 7.7
17.1 x 19.0 x 10.2
【 17.1 x 18.6 x 7.7 】 |
| Weight in LBS | 51.4 |
| Carton Maximum Dimensions (W x D x H) in Inches | 22.4 x 12.9 x 21.2 |
| Carton Weight (inc. product) in LBS | 59.3 |
